For installations in earthquake-prone areas, our structural engineers run finite element dynamic response spectra calculations based on the site's ground acceleration coefficient (Ss, S1) and soil classification. Rather than supplying standard upright frames, we:

A) Upgrade the upright steel section from standard Q235B to heavy-gauge Q355B high-yield structural steel;
B) Enlarge baseplate dimensions to 160 mm × 180 mm × 10 mm (or custom heavy ductile plates) with multiple chemical resin mechanical anchor bolts;
C) Increase horizontal and diagonal bracing frequency in the lower third of the racking bays, and introduce heavy-duty top-tie cross-aisle portal bracing beams to prevent lateral progressive collapse.

To deliver an accurate, code-compliant preliminary layout within 24–48 hours, our design office requires:

• Architectural DWG or dimensioned floor plan highlighting internal column grids, overhead roof clear heights, warehouse fire doors, skylights, and sprinkler drop clearances;
• Pallet load specifications: Width × Depth × Height (inclusive of cargo overhang) and maximum gross weight per pallet;
• Material handling equipment (MHE): Forklift model, mast collapsed height, maximum lift height, and minimum right-angle stacking aisle turning radius (AST);
• Environmental operating parameters: Ambient room temperature, cold storage freezer specs, or chemical hazardous storage zoning.

High humidity and saline coastal environments in Southeast Asia, the Pacific, and the Caribbean can cause premature oxidation on poorly coated steel. HEDA Shelves addresses this through two primary finishing methods:

Thermosetting Polyester Electrostatic Coating: Components undergo a continuous 4-stage immersion pre-treatment (alkaline degreasing, clean water rinse, acid pickling to strip mill scale, and iron-phosphating to form an anti-corrosion barrier). An epoxy-polyester hybrid powder is electrostatically applied and cured at 200°C, producing a non-porous 70–90 μm film that prevents moisture penetration.
Hot-Dip Galvanizing (ISO 1461): For deep freeze environments (-25°C to -40°C) or outdoor/semi-open loading docks, steel components are submerged in molten zinc at 450°C, creating a metallurgically bonded zinc-iron alloy coating (60–100 μm) with self-healing cathodic protection that resists rust for decades.

Because structural racking profiles are long and heavy, unoptimized shipping can result in dead air volume or container axle overweight fees. Our Guangzhou logistics team uses automated 3D container packing software to model every 40ft High Cube (40HQ) load before manufacturing begins:

• Upright columns: Packed in custom-nested bundles wrapped with heavy corrugated cardboard, corner angle protectors, and heavy steel strapping with lifting eyes for rapid forklift unloading;
• Box beams: Alternately nested head-to-tail to balance weight distribution along the container's center of gravity;
• Bracing and accessories: Pre-bundled in high-density steel frames, utilizing the gap volume beneath nested beam stacks to reach full 26–27 metric ton payload limits and minimize shipping costs per pallet position.

Depending on your project's regional jurisdiction, our design team calculates structural load capacities according to:

• European Standards: EN 15512 (Steel Static Storage Systems: Adjustable Pallet Racking Systems), EN 15620 (Tolerances, Deformations and Clearances), and FEM 10.2.02;
• American Standard: ANSI MH16.1 (Specification for the Design, Testing and Utilization of Industrial Steel Storage Racks, published by the Rack Manufacturers Institute • RMI);
• Australian Standard: AS 4084-2023 (Steel Storage Racking). Formal structural calculation packs stamped by accredited structural engineers are available upon contract finalization.
