OEM/ODM Rack System For Storage Manufacturers & Manufacturer Supply
Industrial-grade precision fabrication, custom warehouse steel engineering, certified structural resilience, and scalable manufacturing solutions designed for regional rack brand holders and global supply chains.
25+
Years of OEM/ODM Engineering Experience
30,000m²
Automated Heavy Industrial Fabrication Facility
30,000T
Monthly Structural Steel Production Capacity
120+
Countries and Territories Directly Supplied
Enterprise Product Portfolio
Featured Industrial OEM/ODM Racking Systems
Tailored structural designs, heavy-duty load parameters, and proprietary roll-forming profiles built to international mechanical compliance standards.
Metal Frame Structure Prefabricated Warehouse/Workshop
Turnkey prefabricated portal frames and heavy steel structures optimized for logistics hubs, industrial workshops, and high-clearance hangars.
In modern supply chain ecosystems, warehouse racking has evolved from passive structural steel framing into a precision-engineered operational asset. Sourcing high-capacity pallet racking, cantilever systems, automated shuttle racks, and multi-tier mezzanines requires comprehensive material verification, finite element modeling, and precise manufacturing tolerances. Industrial manufacturers, regional racking distributors, logistics integrators, and project EPC contractors require OEM and ODM partners capable of custom fabrication that satisfies rigorous safety codes while preserving unit economics.
As a tier-one manufacturing partner with over two decades of dedicated production history, Guangzhou Heda Shelves Co., Ltd. addresses the technical divide between architectural concept and structural reality. Operating from a 30,000-square-meter advanced manufacturing facility in South China, our manufacturing line integrates robotic cold-roll profile forming, high-precision automated upright punching, robotic MIG welding, automated multi-stage chemical pretreatment, and environmentally certified electrostatic powder coating systems.
Mechanical Integrity, Steel Grades, and Tolerances
Racking stability begins at the molecular level of structural steel. Our standard OEM/ODM production employs certified structural coil stock such as Q235B and high-yield Q355B (equivalent to ASTM A36 and S355JR). Standard roll profiles utilize progressive multi-stage cold bending to avoid residual micro-stresses along flange radii. By strictly managing gauge tolerances across upright widths (typically 80mm to 140mm) and beam box-channel depths, our components guarantee seamless mechanical interlock, eliminating connector drift and eccentric load displacement.
In compliance with global racking specifications—including the European R-EN 15512, R-EN 15620, and American RMI (Rack Manufacturers Institute) MH16.1—structural members undergo cyclic stress verification, deflection modeling (maintaining span-to-deflection ratios better than 1:200), and automated non-destructive weld testing. For distributors expanding their private-label catalog, this engineering rigor protects brand equity and mitigates catastrophic failure liability on client installations.
Market Forecast & Sourcing Intelligence
Future Procurement Trends for Industrial Storage Systems
How smart infrastructure, supply chain de-risking, and environmental mandates are transforming enterprise racking procurement.
Standardized AS/RS-Ready Design
Logistics hubs are migrating from manual forklift operations to automated shuttle vehicles, AGVs, and autonomous mobile robots (AMRs). OEM procurement increasingly specifies high-tolerance floor rails, dynamic deflector plates, and reinforced connector pins compatible with automated guidance systems.
Near-Zero Carbon & RoHS Surface Treatments
International ESG regulations mandate stringent tracing of volatile organic compounds (VOCs) and hazardous heavy metals. Forward-looking procurement departments prioritize manufacturers utilizing closed-loop phosphating, chromium-free rinses, and durable, 100% recyclable polyester powder coatings.
Seismic & Cold-Chain Resilient Profiles
Rapid supply chain decentralization across seismic zones (Southeast Asia, Japan, Middle East) demands customized base-plate anchor configurations, heavier bracing ratios, and structural finishes capable of withstanding thermal cycling in -30°C blast-freezer operations without embrittlement.
Technological Advancements in Storage Racking Manufacturing
The structural steel storage sector is experiencing a paradigm shift driven by digital manufacturing, sensor integration, and advanced metallurgical processing. The conventional paradigm of mass-producing unmonitored steel uprights is being superseded by data-driven engineering that optimizes steel tonnage while boosting load thresholds.
1. Thin-Walled High-Strength Profile Forming: Through finite element analysis (FEA), our structural engineers optimize cold-formed profiles with multi-ribbed upright cross-sections. This allows a reduced material weight footprint while achieving greater torsional and buckling resistance under asymmetrical load conditions, substantially reducing marine freight costs for overseas importers.
2. Intelligent Tracking & Digital Factory Interfacing: Modern OEM manufacturing contracts require digital continuity. Every production batch of roll-formed beams, cantilevers, and upright frames is tagged with unique traceability identifiers linked to raw material chemical heat numbers, tensile test records, and automated dimensional QA checks.
3. Modular Mezzanine Engineering: Urban real estate constraints in major distribution hubs have made vertical cubic space optimization paramount. Modern structural steel platforms now utilize integrated cold-formed sigma joists, interlocking steel floor deck panels, and pre-punched utility conduits that allow rapid on-site bolt-together assembly without hot work or welding permits.
Manufacturing Protocol
10-Step Quality-Controlled Production Flow
From prime coil selection to protective international export bundling, every phase is executed within our own facilities.
01
Raw Coil Audit
Spectrometric verification of prime Q235B/Q355B coils for yield, elongation, and composition.
02
Precision Slitting
Automated strip slitting ensuring micron-level edge straightness across all strip lengths.
03
High-Speed Punching
Continuous CNC upright column hole punching with consistent center-to-center accuracy.
04
Cold Roll-Forming
Multi-station cold rolling forming smooth radii, eliminating internal metallurgical stress.
05
Laser Profile Sizing
High-precision burr-free cutting ensures square end cuts for consistent mechanical alignment.
06
Robotic Welding
Automated multi-axis robotic gas metal arc welding (GMAW) on beam end connectors.
07
Surface Polishing
Mechanical shot blasting and deburring eliminates slag, preparing metal for chemical binding.
08
Pretreatment Bath
Multi-tank acid pickling and zinc phosphating creates an impermeable anti-corrosion barrier.
09
Electrostatic Coat
Automated powder line cured at 200°C produces an impact-resistant, high-gloss finish.
We bridge the gap between custom design flexibility and heavy industrial mass manufacturing.
Full In-House Engineering & Free 3D Modeling
Distributors and enterprise contractors receive comprehensive 2D CAD engineering schematics, structural floor plans, and photo-realistic 3D rendering designs within 24 to 48 hours of initial brief submittal. Our seasoned engineering staff verifies building columns, sprinkler clear zones, slab bearing pressures, and equipment turning radiuses prior to order finalization.
Certified Structural Compliance (CE & ISO)
We maintain active certifications validating production safety and systematic quality control: official CE Certification (Certificate No. 2435-CPR-8605159), ISO 9001:2015 Quality Management System Certification (No. 18624Q00169R0M), and strict RoHS eco-compliance across all powder paints. Complete mechanical mill test certificates accompany every export bill of lading.
Optimized Global Logistics & Packing Plans
Located close to major South China ocean ports (Guangzhou and Shenzhen), we provide short sea transit routes to Southeast Asia, Australasia, the Middle East, Europe, and the Americas. Every shipment is planned using automated 3D container packing algorithms to optimize freight cube utilization, prevent freight damage, and reduce shipping overhead per pallet position.
Confidential White-Label & OEM Distributor Support
We serve as the silent backbone for leading logistics racking equipment providers worldwide. From custom stamping of customer brand logos, non-disclosure engineering agreements, unique beam locking connector patterns, and bespoke color configurations (RAL matching), we help partners protect and expand their regional market footprint.
Procurement Knowledge Base
Industrial Storage Racking Sourcing FAQ
Key structural, mechanical, and logistical questions addressed by our engineering department.
What parameters are required to calculate structural load capacities for custom racking?
To provide accurate engineering calculations, our design team requires: (1) Pallet footprint dimensions including load overhang (Length x Width x Total Height); (2) Maximum gross unit weight per pallet position; (3) Stacking tier profile and clear warehouse ceiling height below sprinklers/lighting; (4) Forklift specifications including mast lift height, collapsed mast height, and minimum turning radius aisle requirements; and (5) Local seismic zone classifications or floor slab structural load ratings (kN/m²).
How does HEDA guarantee steel durability and corrosion resistance in humid or extreme environments?
Every raw steel component undergoes a rigorous surface conditioning process: immersion degreasing, clean-water rinsing, industrial acid pickling to eliminate scale, followed by iron/zinc phosphating. This forms an inorganic crystalline conversion layer that enhances paint adhesion and inhibits sub-film oxidation. Furthermore, we apply high-purity electrostatic thermoset polyester powders, cured at 200°C. For sub-zero cold chain facilities or coastal high-salinity ports, we supply hot-dip galvanized finishes meeting ISO 1461 specifications.
What OEM/ODM customization options are available for storage equipment distributors?
Our OEM/ODM capabilities encompass custom cold-forming profiles, specific hole-pitch configurations (e.g., 50mm, 75mm, 76.2mm teardrop patterns), tailored beam hook-connector geometries, client-specific electrostatic powder coating RAL matches, embossed or laser-cut corporate trademarks on uprights, and customized instruction manuals, engineering labels, and branded export packaging.
What structural safety documentation is supplied for international permit and building compliance?
We provide full technical documentation packets including: certified steel mill test certificates verifying mechanical chemical compositions, CE Declarations of Conformity under structural regulation EN 1090-1, 3D structural stress analysis reports, comprehensive base-plate dynamic shear and anchorage calculation calculations, component identification maps, and multilingual assembly installation manuals.
