Mracking Medium Duty Warehouse Rack Adjustable Storage Racks and Shelves Selective Pallet Steel Rack Wholesale Sale
Product Description
Product Description
Medium Duty Rack:
Medium duty rack belongs to warehouse storage racking systems. It can be adjusted by each 50mm, and the load capacity can be reach 200~500kg. The beam is "P" type beam, whose height matches with that of the layer board.
| Standards Size | Layer | Loading Weight | Beam (mm) | Upright (mm) | Thickness of Board (mm) |
|---|---|---|---|---|---|
| L2000*D600*H2000 | 4 | 200~300kg/layer | 60*40*1.2 | 60*50*1.2 | 0.5 |
| L2000*D600*H2000 | 4 | 400~500kg/layer | 60*40*1.5 | 60*50*1.5 | 0.7 |
| Product Name | Medium Duty Rack/Shelf |
| Material | High-Quality Q235 Cold-Rolled Steel |
| Loading Capacity | 200~500kgs/level |
| Thickness | Upright: 60*40*1.0, 1.2, 1.5mm; Beam: 60*40 / 80*40*1.0, 1.2, 1.5mm; Steel: 0.5, 0.6, 0.7mm |
| Color | Upright: Blue, Beam: Orange, Steel: Gray white. It can be customized any color. |
| Surface Treatment | Electrostatic Spray Surface |
| Packing Term | Air bubble, Carton, Wooden Case. |
| Warranty | 10 Years |
| Certification | SGS |
- 1. Long span shelving rack is very convenient for installation.
- 2. The adjustment distance of steel layers is 50mm for multiple usages. It is consisted of vertical columns, layer plates, corner pieces, pins, special bolts and plastic footing.
- 3. The surface is electrostatic sprayed and the color is selectable. It has good ability of corrosion protection and rust protection.
- 4. It is widely used in families, stores, supermarkets, company storages and public institutions. It is the most updated products.
Beam Loading Capacity & Size
Detailed Images
Medium Duty Rack Specifications
| Size | L2000*D600*H2000mm, Loading: 300kg/layer, Layer: 4 levels |
| Material | Upright: 60*50*1.0, Beam: 60*40*1.2, Steel: 0.5mm |
| Color | Upright is blue, beam and steel is gray white |
| Packaging Term | Air bubble |
| Surface treatment | Powder Coating |
Beam & Upright Connect
Diagonal & Horizontal Bracing Installed
Steel Board Section
Product Overviews
Frequently Asked Questions
QAre you a manufacturer or trading company?
We are a professional racking manufacturer in Dongguan, Guangdong.
QWhat is the material used for the racks?
Our material is Q235B cold rolled steel.
QWhat is your standard delivery time?
Less than 15 workdays in general. It also depends on the order quantity and shelving design.
QWhat is the term of payment?
30% T/T down payment and 70% T/T before delivery.
QHow can I get a quick quotation on my racking project?
For a quick quotation, please let us know the following information:
1). The size of rack: Length * Depth * Height.
2). Layers per set.
3). Load capacity per beam layer.
4). Racking quantity.
1). The size of rack: Length * Depth * Height.
2). Layers per set.
3). Load capacity per beam layer.
4). Racking quantity.
QHow does your factory handle quality control?
Quality is priority. We have ISO 9001 2001 certifications.
