To generate an accurate 2D/3D CAD layout and structural calculation sheet, our engineering team requires: (1) An architectural layout drawing (AutoCAD DWG or dimensioned PDF) identifying slab boundaries, building columns, and overhead clearances; (2) Detailed pallet parameters including width, depth, height, and maximum dead weight including cargo overhang; (3) Materials handling equipment (MHE) specs, such as forklift model, turning radius (AST), and maximum lift height; and (4) Throughput requirements and SKU counts to determine whether selective, drive-in, or multi-tier mezzanine layouts will yield the best operational efficiency.

For installations located in active seismic areas (including the Pacific Rim zones in Indonesia, the Philippines, Japan, and Taiwan), we do not deploy standard off-the-shelf column sections. Our engineers perform finite element load analysis aligned with local building regulations. We use heavy-duty base plates, enlarged chemical anchors, and reinforced horizontal and vertical cross-bracing frameworks to ensure the racks dissipate seismic lateral forces without joint shearing or upright buckling. Detailed structural calculation packages can be submitted for local municipal and building permit clearance.

Corrosion control begins at the chemical pre-treatment stage. Every steel component processed in our Guangzhou plant undergoes acid pickling to eliminate scale and impurities, followed by a phosphate conversion bath that creates a rust-inhibiting bonding surface. We then apply lead-free, RoHS-compliant thermoset epoxy-polyester powder using automatic electrostatic guns, followed by baking at 180°C–200°C. For industrial cold stores (-30°C), fertilizer storage, or coastal sites subject to marine salinity, we manufacture hot-dip galvanized components (batch dipped in molten zinc per EN ISO 1461) to guarantee multi-decade corrosion defense.

Standard project lead times range from 15 to 25 calendar days depending on steel tonnage and customization details. Because structural racking elements are bulky, proper container stuffing is essential. Our logistics team provides computer-modeled 3D container packing layouts for 20GP, 40GP, and 40HQ units. Heavy upright bundles and pallet beams are packaged using protective steel corner guards, corrugated buffering, and custom wooden cradles to prevent transit distortion. Every shipment includes marked part tags matching the installation assembly blueprint.

Yes. A substantial portion of our 30,000-ton monthly throughput supports regional material handling integrators, racking contractors, and distributor brands worldwide. We support customized upright punch hole pitches (including 50mm, 75mm, and teardrop hole matrices), custom RAL powder colors to match corporate visual identity guidelines, private branding labels on beam connectors, and neutral container packaging for direct drop-shipping to project sites.
