Roll-formed shelving is manufactured from cold-rolled sheet steel formed through multi-stage roller dies into C-sections, omega upright profiles, and step beams. It delivers high strength-to-weight ratios, lower freight costs, and toolless pin adjustability (at 50mm or 75mm pitches), making it suitable for 90% of commercial distribution centers. Structural steel shelving uses hot-rolled structural channels, offering higher impact resistance for heavy forklift operations, but carries significantly higher raw material and freight weights.

UDL ratings assume the weight of goods is distributed evenly across the beam pair, rather than concentrated at a single point. Our calculations follow EN 15512 and FEM 10.2.02 codes. Maximum allowable beam deflection is limited to L/200 (where L equals beam length between upright faces). For a standard 2700mm beam carrying two 1000kg pallets, deflection under full static test loading must remain below 13.5mm, backed by certified safety pins that prevent accidental uplift under forklift operation.

Yes. For distribution projects located along seismic faults (such as Indonesia, the Philippines, Japan, New Zealand, or western South America), our engineers assess ground acceleration values according to local building regulations. We reinforce upright wall gauges (from 1.5mm up to 2.5mm), integrate heavy-duty K-type diagonal bracing trusses, enlarge base footplates, and increase chemical expansion anchor embedding depths to maintain stability during dynamic lateral ground motion.

For humid tropical climates across Southeast Asia and coastal port zones, standard paint can peel under moisture penetration. We subject all bare steel profiles to a 5-stage automated surface bath: degreasing, clean-water rinse, acid pickling, rust removal, and phosphate passivation. Components then receive thermoset epoxy-polyester powder baked at 180°C–200°C. For coastal open-air yards or sub-zero blast freezers, we also provide hot-dip galvanizing with 65–85 micron zinc coatings conforming to ISO 1461.

Every export shipment includes mill test certificates verifying steel grade (Q235B/SPCC chemical composition and yield tensile strength), CE Declaration of Conformity (Certificate No. 2435-CPR-8605159), ISO 9001:2015 Quality Management certification, RoHS non-toxicity test reports, container packing distribution diagrams, and signed structural load validation documents for submission to local municipal building inspection departments.
